The mmWave-UPM Lab is a state-of-the-art 5G research facility specializing in FR2 over-the-air (OTA) testing, fully compliant with 3GPP conformance standards.

This unique UPM facility provides comprehensive OTA testing in accordance with 3GPP TS 38.521, covering both uplink and downlink directions: transmit power, power dynamics, signal quality, RF spectrum, Rx sensitivity, and adjacent channel selectivity, across a wide temperature range from –40 to 85 °C.

The mmWave-UPM Lab enables precise validation of next-generation user equipment under real-world and thermal stress conditions.

EQUIPMENT

ATS1800C Compact Antenna Test Range

Indirect Far Field Anechoic Chamber for mmWave Over-the-Air (OTA) measurements.

• Frequency range: 6 GHz – 92 GHz (in-band 23.5–44.3 GHz)

• Quiet Zone (QZ): 40 cm diameter.

• Integrated dual-polarized feed antennas.

• DUT positioner: Azimuth and elevation ±181°, resolution 0.01°, load up to 8 kg

CMX500

5G base station emulator for conformance and signaling tests.

• Frequency range: FR1 (sub-6 GHz) and FR2 (24.25 – 52.6 GHz)

• Supports Standalone (SA) and Non-Standalone (NSA) 5G modes

• Maximum data rate: 20 Gbps

• Supports TDD/FDD, beamforming control, and dual-carrier aggregation

FSW85

High-performance spectrum analyzer FR1 and FR2.

• Frequency range: 2 Hz – 90 GHz

• Frequency resolution 0.01 Hz

• Minimum sensitivity without preamplifier: −155 dBm

• Supports TRP, EIRP, spurious emission, and phase noise tests

CMX-RF42

RF up-/down-conversion and amplification for FR2 signal paths.

• Frequency range: 24 GHz – 44 GHz

• Supports uplink (UL) and downlink (DL) conformance paths

• Low-noise amplifier for receiver path; variable gain for transmitter path

• Ensures proper SNR and dynamic range for TRP/EIRP testing

MPI TA-5000 – Thermal Streamer

Temperature control system for DUT environmental testing.

• Temperature range: –40 °C to +85 °C

• Stability: ±1 °C; programmable thermal cycling

• Provides hot/cold airflow directly into the DUT chamber

• Temperature resolution: 0.1ºC

CAPABILITIES

The mmWave-UPM Lab is equipped to perform comprehensive 5G FR2 device testing across both unlicensed and licensed frequency bands, including the 24 GHz band and the n258 (26 GHz), n257 (28 GHz), n260 (39 GHz), n259 (41 GHz) bands. This capability enables end-to-end evaluation of next-generation user equipment under realistic operating conditions.

TEST CASES

5G FR2 Standalone (SA)

In Standalone mode, the mmWave-UPM Laboratory operates a complete 5G New Radio (NR) system

Products / Materials tested	Type of test		Standard Specifications / Test procedure
5G User Equipment (UE): smartphones, tablets, laptops, FWA and others.	UE Conformance tests. Frequency Range 2 Operation. Applicability to stand-alone Radio Transmission: 5G Tx FR2 (SA)	UE Maximum Output Power	3GPP TS 38.521-3 ETSI TS 138 521-3 Ver 18. Clause 6.1 to 6.4 3GPP TS 38.521-4 ETSI TS 138 521-4 Ver. 18 Clause 4.5, 7.1 to 7.5
		On/Off Behavior
		Power Tolerance
		Frequency / Modulation
		Bandwidth and emissions
		Spurious Emissions
		CA-specific In-band emissions
		CA Occupied Bandwidth
	UE Conformance tests. Frequency Range 2 Operation. Applicability to stand-alone Radio Reception: 5G Rx FR2 (SA)	Receiver Performance	3GPP TS 38.521-3 ETSI TS 138 521-3 Ver 18. Clause 7.1 to 7.9 3GPP TS 38.521-4 ETSI TS 138 521-4 Ver. 18 Clause 4.5, 7.1 to 7.5
		Maximum Input
		In-band measurments
		Out-of-band measurements
		Beam management
		Maximum Input
		In-band measurements
		Out-of-band measurements

5G FR2 non-Standalone (NSA)

Products / Materials tested	Type of test		Standard Specifications / Test procedure
5G User Equipment (UE): smartphones, tablets, laptops, FWA and others.	UE Conformance tests. Frequency Range 1 and 2 EN-DC Interworking Operation. Applicability to non-stand-alone Radio Transmission: 5G Tx FR1-FR2 (NSA)	UE Maximum Output Power	3GPP TS 38.521-3 ETSI TS 138 521-3 Ver 18. Clause 6.1 to 6.4 3GPP TS 38.521-4 ETSI TS 138 521-4 Ver. 18 Clause 4.5, 7.1 to 7.5
		On/Off Behavior
		Power Tolerance
		Frequency / Modulation
		Bandwidth and emissions
		Spurious Emissions
	UE Conformance tests. Frequency Range 1 and 2 EN-DC Interworking Operation. Applicability to non-stand-alone Radio Reception: 5G Rx FR1-FR2 (NSA)	Receiver Performance	3GPP TS 38.521-3 ETSI TS 138 521-3 Ver 18. Clause 7.1 to 7.9 3GPP TS 38.521-4 ETSI TS 138 521-4 Ver. 18 Clause 4.5, 7.1 to 7.5
		Maximum Input
		In-band measurements
		Out-of-band measurements
		Beam management
